We offer steel and steel fabrication services

We are a first-class steel service center with industry-leading technology, offering a wide range of steel and processing services to our customers.

Leave a Message

Q420 high strength steel plate

Get in touch

High Strength Steel Plate Description

High Strength Steel Plate is one such type of plate that has improved strength, formability, and weldability. They also display better resistance to atmospheric corrosion as compared to other conventional steel. High Strength Steel Plate is used due to a number of reasons. Firstly, the structural section can be reduced by increasing the strength of the steel. This in turn reduces the erection and fabrication cost.


High Strength Carbon Steel Plate can also be used to reduce the size of the structural element. This makes it possible to develop elegant and aesthetically appealing structures. These High Tensile Plates can improve their strength by adding an alloying element such as carbon and manganese. However, the drawback of these elements is that they at times worsen the fabrication properties such as weldability. Ultra High Strength Steel Plate can have a fine grain structure resulting in higher tensile strength. This issue to the heat treatment that these High Strength Steel Sheets are passed through.

We use a conventional hot rolling method for the production of these plates. This is followed by normalizing these plates. To obtain a fine and homogenous structure of High Tensile Steel Plate this method is used. They are widely used in the production of passenger vehicles. The reason being these High Tensile Steel Sheets For Automobiles are light in weight. The best way for automobile manufacturers to enhance the performance of the machine is to reduce the weight of the product. These High Strength Hot-rolled Steel Sheets For Automobiles help in achieving this target. They are hence used in a number of automobile productions such as trains, buses, planes, and trucks.



High Tensile Strength Steel Plate has an alloying content of titanium and molybdenum which makes it suitable for bending and heat treating. They are commonly used in steel frames, pipe works, and load bearing beams. High Strength Weldable Steel plates can be welded manually or using automatic modern equipment. Both these techniques give the same end results and do not hamper the property.

Q390 high strength steel plate
Get Free Quote
S355 high strength steel plate
Get Free Quote
Q550 high strength steel plate
Get Free Quote
Q460 high strength steel plate
Get Free Quote
Q420 high strength steel plate
Get Free Quote

Q420 high strength steel plate description

Q420 steel is a Chinese steel grade of Low Alloy High Strength Structural Steel, Yield Strength is 420 MPa, parameters are tested with 16mm diameter steel bars or steel plates, and tensile strength is 520-680 Mpa, the material density is 7.85 g/cm3. According to GB/T 1591-2008, Q420 has 5 quality levels: Q420A, Q420B, Q420C, Q420D and Q420E.


Q420 high strength steel plate advantage

Q420 steel has high strength, especially in normalized or normalized plus tempered state, with high comprehensive mechanical properties, can be used in large ships, bridges, power station equipment, medium and high pressure boilers, high pressure vessels, lifting machinery, mining machinery and other large welded structural parts.


Q420 high strength steel plate Chemical Composition

  Chemical Composition % (GB/T 1591 – 2008)
Steel GradeGradeC (≤)Si (≤)Mn (≤)P (≤)S (≤)Nb (≤)V (≤)Ti (≤)Cr (≤)Ni (≤)Cu (≤)N (≤)Mo (≤)B (≤)Als (≥)
Q420Q420A0.200.501.700.0350.0350.070.200.200.300.800.300.0150.20
Q420B0.0350.035
Q420C0.0300.0300.015
Q420D0.0300.0250.015
Q420E0.0250.0200.015


Q420 high strength steel plate specification

Product Name

high strength steel plate

Length

1m-12m or as required

Width

0.6m-3m or as required

Thickness

3mm-300mm or as required

Standard

AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.

Technique

Hot rolled High strength, high yield point

Surface Treatment

Clean, blasting and painting according to customer requirement

Thickness tolerance

±0.1mm



Material

Q390 Q420 Q460 Q500 Q550 Q690 SAPH310,SAPH370,SAPH400,APH440,SPC590DU,SPFC540,SPFC390,SPFH540,SPFH590
,SPC980DU,SPF*40,ZStE340,S315MC,ZQS500L,SPC270、440,SPCEN,SM490A,St52-3,ZStE420,J S*40W,ZStE380,B610 L,HC500LA,B250P1,Q345B

Application

It is mainly used to make structural parts such as car girder, beam, transmission shaft and car chassis parts, which can reduce the weight of the parts.

MOQ

25tons.We also can accept sample order.

Shipment time

Within 15-20 workdays after receiving deposit or L/C

Export packing

Waterproof paper, and steel strip packed.
Standard Export Seaworthy Package.Suit for all kinds of transport,or as required

Capacity

250,000 tons/year


Quick Browse

close play pause

Industries We Proudly Service

Industries We Proudly Service

Building Construction
Specific requests for on-site construction are generally required and we will work with our clients to meet their needs.
Oil & Gas
We supply high strength steel to the oil and gas industry and our equipment is customized to cut advanced high strength steel for the oil and gas industry.
Medica Equipment
TISCO supplies hospital beds and related furniture applications that require low micro surface finishes for plating applications.
Spaceflight
Our high-quality steels and aircraft-grade metals also play an important role in specialty aerospace parts.
Agriculture
TISCO has been a proud supplier of steel to the agriculture and farming industry, and we understand the ups and downs that the industry has experienced.
Heavy Equipment
We also supply several exercise equipment manufacturers with special high surface quality and high strength applications.

Can I go to your factory to visit?

Of course, we welcome customers from all over the world to visit our factory.
Q : How long is your delivery time?
A : Our daily inventory is more than 6000 tons, so for common product size, just need 5-7 work days from stocks, ifthe special size from new production, delivery 15-21 days.
Q : Does the product have quality inspection before loading?
A : Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.we accept third party inspection.
Q : Can you accept customization?
A : Yes. Can be customized according to customer requirements
Q : How do we trust your company?
A : We specialise in steel business for years as golden supplier on Alibaba, headquarter locates in Jinan, Shandong province, you are welcome to investigate in any ways, by all means, we have CE and ISO9001 certificate, quality can be guaranteed, the most important point is that we ship enough weight as per the order.
Q : What's your supported standard of products?
A : We can supply BG/T, ASTM;, EN/DIN,; JlS and other common standards products. Customers can name their requests and we can supply accordingly.
