| Steel Grade | Mass fraction, % based on heat and product analyses a,g | ||||||
| C | Mn | P | S | V | Nb | Ti | |
| max b | max b | max | max | max | max | max | |
| Seamless Pipe | |||||||
| A | 0.22 | 0.9 | 0.3 | 0.3 | – | – | – |
| B | 0.28 | 1.2 | 0.3 | 0.3 | c, | c, | D |
| X42 | 0.28 | 1.3 | 0.3 | 0.3 | |||
| X46 | 0.28 | 1.4 | 0.3 | 0.3 | |||
| X52 | 0.28 | 1.4 | 0.3 | 0.3 | |||
| X56 | 0.28 | 1.4 | 0.3 | 0.3 | |||
| X60 | 0.28 e | 1.40 e | 0.3 | 0.3 | f | f | f |
| X65 | 0.28 e | 1.40 e | 0.3 | 0.3 | f | f | f |
| X70 | 0.28 e | 1.40 e | 0.3 | 0.3 | f | f | f |
| Welded Pipe | |||||||
| A | 0.22 | 0.9 | 0.3 | 0.3 | – | – | – |
| B | 0.26 | 1.2 | 0.3 | 0.3 | c, | c | |
| X42 | 0.26 | 1.3 | 0.3 | 0.3 | |||
| X46 | 0.26 | 1.4 | 0.3 | 0.3 | |||
| X52 | 0.26 | 1.4 | 0.3 | 0.3 | |||
| X56 | 0.26 | 1.4 | 0.3 | 0.3 | |||
| X60 | 0.26 e | 1.40 e | 0.3 | 0.3 | f | f | f |
| X65 | 0.26 e | 1.45 e | 0.3 | 0.3 | f | f | f |
| X70 | 0.26e | 1.65 e | 0.3 | 0.3 | f | f | f |
| a. Cu ≤ = 0.50% Ni; ≤ 0.50%; Cr ≤ 0.50%; and Mo ≤ 0.15%, b. for each reduction of 0.01% below the specified max. concentration for carbon, and increase of 0.05% above the specified max. concentration for Mn is permissible, up to a max. of 1.65% for grades ≥ B, but ≤ = X52; up to a max. of 1.75% for grades X52, but X70; and up to a maximum of 2.00% for X70., c. Unless otherwise agreed NB + V ≤ 0.06%, d. Nb + V + TI ≤ 0.15%, e. Unless otherwise agreed., f. Unless otherwise agreed, NB + V = Ti ≤ 0.15%, g. No deliberate addition of B is permitted and the residual B ≤ 0.001% | |||||||
The API 5L specification covers seamless and welded steel pipe wires. It includes standard weight and super threaded pipe. It includes standard weight and super threaded pipe; Standard weight flat end, conventional weight flat end, special flat end, super flat end, special flat end, super flat end tube; As well as socket and through-line (TFL) pipes. The purpose of this Code is to provide standards for pipelines suitable for the transportation of gases, groundwater and petroleum in the oil and gas industry.
Tianjin TIsco has extensive industry experience, an expert staff, and state-of-the-art equipment.
