1Cr5Mo heat-resistant steel can resist corrosion generated during petroleum cracking. 1Cr5Mo heat-resistant steel is used for reheat steam pipes, petroleum cracking pipes, boiler hangers, steam turbine cylinder liners, pump parts, valves, piston rods, high-pressure hydrogenation equipment components, fasteners, etc.
Characteristics: It has good oxidation resistance, corrosion resistance, and tissue stability. High thermal strength performance and good process performance.
1Cr5Mo is equivalent to ASTM or ASMESA387 Gr5 in the United States (5Cr-0.5Mo)
Executive standard for 1Cr5Mo steel plate: GB/T 1221-1992
1Cr5Mo steel plate delivery status: Normalized, tempered, normalized and tempered, quenched and tempered. Delivery status can also be specified according to technical requirements.
| Grade | C | Si | Mn | Cr | P | S | Mo | Ni |
| 1Cr5Mo | ≤0.15 | ≤0.50 | ≤0.60 | 4.00-6.00 | ≤0.03 | ≤0.02 | ≤0.45-0.60 | ≤0.6 |
| Grade | Yield Strength (MPa) | Ultimate Tensile Strength (MPa) | Elongation at Break (%) |
| 1Cr5Mo | ≥390 | ≥590 | ≥18 |
| Material | Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy |
| Shape | Bar,Pipe/tube,sheet/plate,Forging,Ring,Coil,Flange,Ribbon,Square pipe/bar, |
| Grade | Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L |
| Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc | |
| Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC | |
| Incoloy: Incoloy 800/800H/800HT/825/925/926;etc | |
| GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc | |
| Monel: Monel 400/K500/R405,etc | |
| Nitronic: Nitronic 40/50/60;etc | |
| Nimonic: Nimonic 75/80A/90/A263 ;etc | |
| Specification | Wire: 0.01-10mm |
| Strip: 0.05*5.0-5.0*250mm | |
| Bar: φ4-50mm;Length 2000-5000mm | |
| Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm | |
| Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm | |
| Product | 1.According to the preparation process can be divided into deformation superalloys, |
| Characteristics | casting superalloys and powder metallurgy superalloys. |
| 2.According to the strengthening mode, there are solid solution strengthening type, precipitation | |
| strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc.. | |
| Inspection | ISO,SGS,BV and so on. |
| Packaging | All our products are packed, stored, transported according to the international regulation.Or as customer's requirement provide special packing. |
