Length Requirements for ASTM A252 Pipes

The length specs for ASTM A252 pipes are as follows

Single Random Length (SRL)- 16 to 15 feet
Double Random Length (DRL)- Average 35 ft, with a minimum length of 25 feet.
Uniform lengths under ASTM A252 should be as specified with an available variation of +/- 1 inch.

Chemical Specifications for ASTM A252 Pipes

As for its mechanical properties, under ASTM A52 Specs, the maximum phosphorus content in piling pipes should not exceed 0.50%. This limit is necessary because this substance can make the steel brittle while adversely affecting the steel's welding capabilities. The other elements used in a pile should be administered according to the general requirements of carbon steel pipes.

Types of Pipe Ends Permissible According to ASTM A252 Specifications

According to these standards, all pipes should have a standard plain end unless otherwise specified. Steel pipe piles should either possess machine-cut or flame-cut ends. Manufacturers must also remove the burrs at the ends of these pipes.

In cases where beveled edges are permissible, certain specifications must be maintained. According to ASTM A252 standards, all beveled-ended pipe piles must have an angle of 30 degrees +5, -0 degrees. These edges must be obtained by drawing a perpendicular line from the axis of the pipe pile.

Tensile Measurements for ASTM A252 Grade 3 Pipes

Grade Yield Point Min. Elongation at 2° Tensile Strength Min. Elongation at 8°
3 45000 psi 20% 66000 psi …

Calculated Minimum Elongation Values of ASTM A252 Grade 3 Pipes

Nominal Wall Thickness in Inches	Minimum Elongation % in 2 Inches for ASTM A252 Grade 3
5/16 or 0.312 inch	20.00
9/32 or 0.281 inch	19.00
¼ or 0.250 inch	18.00
7/32 or 0.219 inch	17.00
3/16 or 0.188 inch	16.00
11/64 or 0.172 inch	16.00
5/32 or 0.156 inch	15.00
9/64 or 0.141 inch	14.00
1/8 or 0.125 inch	14.00
7/64 or 0.109 inch	13.50
